Description
INNER LINER
Conductive Teflon®
REINFORCEMENT
One braid of stainless steel wire
OUTER COVER
Black and blue fire retardant/abrasion resistant aramid polyester
TEMPERATURE RANGE
-20ºC up to +125ºC
SAFETY FACTOR
4:1
VACUUM RATING
N/A
APPLICATION
High pressure hose for transfer of natural gas/town gas/LPG and butane-propane on stationary and mobile LPG gas engines. Ideal for forklift/automotive/light & medium duty truck and transfer
FEATURES
Exceptional flexibility. Abrasion resistant cover. Very low extractable & permeation rate. Easy to install.
SPECIFICATIONS/PERFORMANCE
• AS 1869 Class D
• AGA (Aust. Gas Association) approved
Specifications
| Item | ID – inch | ID – mm | OD (avg) – mm | Max. W.P – bar | Max. W.P – psi | Min. Bend Radius – mm | Weight – Kg/m | Notes |
|---|---|---|---|---|---|---|---|---|
| LPG-06 | 5/16 | 7.9 | 13.6 | 26 | 377 | 101 | 0.18 | |
| LPG-10 | 1/2 | 12.7 | 19.1 | 26 | 377 | 165 | 0.27 | Limited stock available |
COMPATIBLE HOSE COUPLINGS
| Hose Size | Crimp |
| -06 | G |
| -10 |
